What does USB-C PD mean?

USB-C PD means USB Type-C Power Delivery. It allows a compatible device and power supply to communicate and select the required voltage and current. This enables the EU106A USB-C PD Desktop Adaptor to support equipment with different power requirements through one USB-C connection. Read our guide to USB-C Power Delivery to learn more.

What output voltage does the EU106A provide?

The EU106A supports output profiles of 5, 9, 12, 15 and 20 Vdc. A single unit supplies one negotiated voltage at a time according to the requirements of the connected USB-C PD device. The 65W USB-C Charger can provide up to 3.25 A at 20 Vdc.

Does the EU106A use GaN technology?

Yes. The EU106A is a GaN Power Supply incorporating gallium nitride semiconductor technology. GaN supports efficient high-frequency switching and increased power density, helping the adaptor deliver up to 65 W from a compact desktop enclosure.

What applications is the EU106A suited to?

The EU106A is suitable for compatible industrial and professional equipment requiring up to 65 W through USB-C. Typical applications include HMIs, IoT gateways, industrial handheld terminals, networking equipment, embedded computing systems and portable test or diagnostic devices.

What AC input options are available for the EU106A?

The EU106A operates from a universal 100–240 Vac input and is available with C8 or C6 AC inlets as standard options. The required inlet should be specified when ordering. Please contact Relec Electronics to discuss the correct configuration for your equipment and target market.

EU106A Series

The EU106A Series is a compact 65 W GaN USB Type-C PD charger designed for commercial and ITE applications. Supporting USB Power Delivery 3.0, QC 4.0 and QC 4.0+, it provides output profiles of 5, 9, 12, 15 and 20 Vdc, with up to 3.25 A available at 20 Vdc. Its universal 100–240 Vac input and choice of C8 or C6 AC inlet support integration into equipment for international markets.

The charger meets Energy Efficiency Level VI requirements and consumes no more than 0.21 W under no-load conditions. Automatic protection covers short circuit, overvoltage and overcurrent conditions, with optional overtemperature protection. Additional features include an LED indicator, an MTBF exceeding 100,000 hours and a compact 90 × 40 × 27 mm enclosure. Safety approvals include UL 62368-1, EN 62368-1, IEC 62368-1, FCC, CE, UKCA and PSE.

Add to Quote

Add to Compare

Category: AC-DC Power Supplies, Plugtop Power Supplies, USB-C PD Adaptors

Brands: EDAC POWER

download the EU106A Series data sheet

Access detailed specifications, performance data, and technical drawings for the EU106A Series in our comprehensive datasheet.

View downloads

Need a 3D drawing?

Our engineers can provide detailed 3D drawings to help you visualise dimensions, mounting, and integration before production.

request a drawing

Stuck on specs? Let’s chat

We’re online and ready to chat.

Open chat

The EU106A Series USB-C PD desktop Adaptor

The EU106A Series is a compact USB-C PD Desktop Adaptor delivering up to 65 W through USB Power Delivery 3.0. It supports 5, 9, 12, 15 and 20 Vdc output profiles, allowing the connected device and 65W USB-C Charger to negotiate the appropriate voltage.

This GaN Power Supply combines a universal 100–240 Vac input with C8 or C6 AC inlet options. Its compact 90 × 40 × 27 mm enclosure, Level VI efficiency and integrated protection make it suitable for compatible industrial computers, HMIs, IoT equipment, networking devices and embedded systems requiring reliable USB-C power.
