DC-DC Converters
Relec supplies a comprehensive range of DC-DC converters designed to provide reliable, efficient DC power conversion across industrial, railway, medical, telecommunications, defence and e-mobility applications. Our portfolio includes isolated and non-isolated DC-DC, PCB mount, DIN rail, chassis mount, rack mount, IP-rated and bi-directional converters, with power ratings from 1W to 6kW. Available with fixed and wide input voltage ranges, including 2:1, 4:1 and 16:1 options, our DC-DC support everything from compact embedded electronics to high-power industrial systems. Whether you need an off-the-shelf module or a customised power conversion solution, Relec’s experienced engineers can help you specify the right product for your application.
Showing 49–64 of 100 results
-
DRD40 Series
Input Range: 10-32V dc
Output Range: 5-24V
Power: 40W
Form Factor: DIN-rail
Cooling Method: Free air convection
Certifications: UL/EN62368, -
EBM Series
Input Range: 9-36 V dc
Output Range: 5V-24V
Power: 120W
Form Factor: Eighth-brick
Cooling Method: Baseplate conduction
Certifications: UL60950-1, EN60950-1 -
EC5A Series
Input Range: 9-32V dc
Output Range: 3.3V-15V
Power: 5W
Form Factor: SIP / DIP
Cooling Method: Free air convection
Certifications: UL62368-1, EN62368-1, EN50155 -
EC7AW18 Series
Input Range: 8.5-160V dc
Output Range: 5V-±15V
Power: 10W
Form Factor: Encapsulated module
Cooling Method: Free air convection
Certifications: UL62368-1, EN50155, EN45545-2 -
EC7AW18-ECRT
Input Range: 10–160Vdc
Output Range: 5Vdc, 12Vdc, 15Vdc,±5Vdc, ±12Vdc, ±15Vdc.
Power: 10W
Form Factor: Enclosed chassis-mount DC-DC converter
Cooling Method: Baseplate cooled (natural convection)
Certifications: IEC/EN/UL 62368-1, EN50155, EN50121-3-2, EN45545-2, EN55032, EN55035, CE, UKCA -
EC7AW18-EDRT
Input Range: 10–160Vdc
Output Range: 5Vdc, 12Vdc, 15Vdc,±5Vdc, ±12Vdc, ±15Vdc.
Power: 10W
Form Factor: Enclosed Din rail mount DC-DC converter
Cooling Method: Baseplate cooled (natural convection)
Certifications: IEC/EN/UL 62368-1, EN50155, EN50121-3-2, EN45545-2, EN55032, EN55035, CE, UKCA -
EC7BW18 Series
Input Range: 10-160V dc
Output Range: 5V-±24V
Power: 20W
Form Factor: Chassis mount / DIN-rail
Cooling Method: Baseplate conduction
Certifications: EN50155, EN45545-2, UL62368-1 -
EC7BW18-72 Series
Input Range: 8.5-160V dc
Output Range: 5-±24V
Power: 20W
Form Factor: 2″ x 1″ isolated module
Cooling Method: Free air convection
Certifications: UL62368-1, EN50155, EN45545-2 -
ECB40W18-ECRT/EDRT Series
Input Range: 9-160V dc
Output Range: 3.3V-48V
Power: 40W
Form Factor: Encapsulated / DIN-rail module
Cooling Method: Conduction via baseplate
Certifications: EN50155, EN45545-2, UL62368-1 -
ECLB40W Series
Input Range: 9-36V / 18-75V dc
Output Range: 3.3-24V
Power: 40W
Form Factor: Low-profile case
Cooling Method: Free air convection
Certifications: IEC/EN/UL62368-1 -
ECLB60W Series
Input Range: 9-36V / 18-75V dc
Output Range: 3.3-48V
Power: 60W
Form Factor: Low-profile case
Cooling Method: Free air convection / conduction
Certifications: IEC/EN/UL62368-1 -
ECLB75W Series
Input Range: 9-36V / 18-75V dc
Output Range: 5-48V
Power: 75W
Form Factor: PCB Mount
Cooling Method: Baseplate conduction
Certifications: UL62368-1, EN62368-1, IEC62368-1 -
FN1-B3N Series
Input Range: Fixed 3.3V / 5V / 12V / 15V / 24V dc
Output Range: 3.3V to ±24V
Power: 1W
Form Factor: SIP
Cooling Method: Free air convection
Certifications: UL94 V-0 -
FN2-xxSxxC3N Series
Input Range: Fixed (5V, 12V, 24V dc)
Output Range: 3.3V-24V
Power: 2W
Form Factor: SIP
Cooling Method: Free air convection
Certifications: UL94 V-0 -
FN2-xxxxxCN Series
Input Range: Fixed (5V, 12V, 15V, 24V dc)
Output Range: 3.3V-±24V
Power: 2W
Form Factor: SIP
Cooling Method: Free air convection
Certifications: UL94 V-0 -
FXP Series
Input Range: 9-36V
Output Range: 24-54V
Power: 1000W
Form Factor: Full-brick
Cooling Method: Baseplate conduction
Certifications: UL60950-1, IEC/EN60950-1, RoHS
