DC-DC Converters
Showing 1–16 of 40 results
-
CBI485A Series
Input Range: 21-75V dc
Output Range: 27.6V
Power: 240W
Form Factor: DIN-rail module
Cooling Method: Natural convection
Certifications: EN62368-1, EN61010-1 -
CBS-10K Series
Input Range: 16.8-138V dc
Output Range: 500V
Power: 6000-10000W
Form Factor: Enclosed chassis
Cooling Method: Internal fan
Certifications: EN62368-1, EN50155, EN45545-2 -
CFB600-300S Series
Input Range: 180-425 Vdc
Output Range: 12-48V
Power: 600W
Form Factor: Full-brick module
Cooling Method: Baseplate conduction
Certifications: UL62368-1, EN62368-1, EN50155 -
CFB600W-110S-CMFD Series
Input Range: 43-160V dc
Output Range: 12-48V
Power: 600W
Form Factor: Chassis Mount
Cooling Method: Baseplate conduction
Certifications: UL62368-1, EN50155, EN45545-2 -
CHB100-110S Series
Input Range: 66-160V dc
Output Range: 12-48V
Power: 100W
Form Factor: Half-brick
Cooling Method: Conduction / free air convection
Certifications: UL60950-1, EN50155, CE -
CHB150W12 Series
Input Range: 14-160V dc
Output Range: 5-48V
Power: 150W
Form Factor: Half-brick
Cooling Method: Baseplate conduction
Certifications: UL62368-1, IEC62368-1, EN50155, EN45545-2 -
CHB200W-110S Series
Input Range: 43-160V dc
Output Range: 5V-48V
Power: 200W
Form Factor: Half-brick
Cooling Method: Baseplate conduction
Certifications: UL60950-1, EN50155, EN45545-2 -
CHB200W12 Series
Input Range: 14-160V dc
Output Range: 12-48V
Power: 200W
Form Factor: Half-brick module
Cooling Method: Baseplate conduction
Certifications: UL62368-1, EN62368-1, EN50155 -
CHB200W12-72S-CMFD Series
Input Range: 14-160V dc
Output Range: 5V-54V
Power: 200W
Form Factor: Half-brick
Cooling Method: Baseplate conduction
Certifications: EN50155, EN45545-2, UL62368-1 -
CHB300W-110S Series
Input Range: 43-160V dc
Output Range: 5-48V
Power: 300W
Form Factor: Half-brick
Cooling Method: Conduction / free air convection
Certifications: UL60950-1, EN50155, EN45545-2 -
CHR Series
Input Range: 16.8-160V dc
Output Range: 12V-54V
Power: 300W
Form Factor: Chassis mount
Cooling Method: Baseplate conduction
Certifications: EN50155, EN45545, UL62368-1 -
CLS-120 Series
Input Range: 14.4-154V dc
Output Range: 12V-48V
Power: 120W
Form Factor: 3U Eurocard
Cooling Method: Natural convection
Certifications: EN50155, EN45545-2, EN62368-1 -
CQB100-110S Series
Input Range: 66-160V dc
Output Range: 3.3-24V
Power: 100W
Form Factor: Quarter-brick
Cooling Method: Conduction / free air convection
Certifications: IEC/EN/UL62368-1, EN50155, EN61373 -
CQB100W14 Series
Input Range: 12-160 Vdc
Output Range: 5V-54V
Power: 100W
Form Factor: Quarter-brick
Cooling Method: Baseplate conduction
Certifications: EN62368-1, EN50155, EN45545-2 -
CQB150W-110S Series
Input Range: 43-160V dc
Output Range: 3.3-48V
Power: 150W
Form Factor: Quarter-brick
Cooling Method: Conduction / free air convection
Certifications: UL60950-1, EN50155, EN45545-2, CE -
CQB150W8 Series
Input Range: 9-75V dc / 18-150V dc
Output Range: 5V-54V
Power: 150W
Form Factor: Quarter-brick
Cooling Method: Baseplate conduction
Certifications: UL62368-1, EN50155, EN45545-2
