19 Inch Rack Mount AC DC Power Supplies

Relec Electronics have a wide range of 19 inch rack mount power supply modules for industrial, telecoms, transportation and military use.  Our 19 inch rack mount power supplies covers euro-cassette modules up to 250W and racks in 1U and 2U formats with power levels up to 12kW

Front end power supplies are used in a wide variety of applications where high reliability and availability are of paramount importance. The hot swap facility allows users to resize or replace modules as their system requirements change. Relec can offer a variety of rack and shelf solutions to complement the power supplies and take full advantage of the hot swap capabilities. Front end power systems are available in DPA & IBA formats and include I2C interface monitoring and control, active current share with ORing FETs and compact, low profile packages that fit in 1U height constraints.

There is a wide range of accessories available including front panels & connectors which our technical sales team would be happy to help you with.

We can also support you with semi custom solutions, should your output voltages not be matched by the standard devices listed below.

READ MOREREAD LESS
  • M Series (ac)

    Input: 85-264Vac
    Outputs: 5 to 48Vdc
    Power: 50 Watt
    Tamb: -40 to +71°C
    Dims: 168 x 111 x 40mm (3U x 8TE)
    UL / CE EN60950 Approved
    5 year warranty

  • S Series (ac)

    Input: 85-264Vac
    Outputs: 5 to 48V
    Power: 100 Watt
    Tamb: -40 to +71°C
    Dims: 168 x 111 x 60mm (3U x 12TE)
    UL / CE EN60950 Approved
    5 year warranty

  • K Series (ac)

    Input: 85-264Vac
    Outputs: 5 to 48V
    Power: 150 Watt
    Tamb: -40 to +71°C
    Dims: 168 x 111 x 80mm (3U x 16TE)
    UL / CE EN60950 Approved
    5 year warranty

  • KP Series (ac)

    Input: 85-264Vac
    Outputs: 5 to 48Vdc
    Power: 250 Watt
    Tamb: -40 to +61°C
    Dims: 168 x 111 x 80mm (3U x 16TE)
    UL / CE EN60950 Approved

  • LR series

    Input: 90 to 264Vac
    Outputs: 12 to 30V
    Power: 300 Watt
    Tamb: -40 to +71°C
    Dims: 168 x 111 x 80mm (3U x 16TE)
    UL / CE EN62368 Approved
    5 year warranty

  • CPA Series

    Input: 85-264Vac
    Outputs: 3V3, 5V, 12V, 12V dc
    Power: 250-500 Watt
    Tamb: -25°C to +50°C
    Dims: 3U or 6U CPCI modules
    UL / CE EN60950 Approved

  • FXP Series

    Input: 85-265Vac
    Outputs: 32 to 51.8V
    Power: up to 5400 Watt
    Tamb: 0 to +70°C
    Dims: 1U x 400 mm
    UL / CE EN60950 Approved

  • Aspiro 1U Series

    Input: 85-264Vac
    Outputs: 54V dc nom
    Power: 400 to 2400 Watt
    Tamb: -40 to 71°C
    Dims: 1U x 280mm
    UL / CE EN60950 Approved

  • TET2500 series

    Input: 90 - 180 VAC/180 - 264 VAC
    Outputs: 12V dc
    Power: 3000W
    Tamb: 0 to +50°C
    Dims: 195 x 86 x 40.0 mm
    Titanium efficiency / Best in class

  • PFE3000 series

    Input: 100-300Vac
    Outputs: 12V or 360V dc
    Power: 3000W
    Tamb: 0 to +45°C
    Dims: 603.7 x 69 x 42 mm
    Platinum efficiency / OCP Compatible

  • TET3000 series

    Input: 90-300Vac
    Outputs: 12V dc
    Power: 3000W
    Tamb: 0 to +50°C
    Dims: 583 x 69 x 40.5 mm
    Titanium efficiency / Best in class

  • TCP3500 series

    Input: 180-528Vac 3ph
    Outputs: 28V to 90V dc
    Power: 3500W
    Tamb: 0 to +70°C
    Dims: 410 x 103 x 84.6 mm
    Conduction or liquid cooled

  • TXP3500 series

    Input: 180-528Vac 3ph
    Outputs: 48V to 110V dc
    Power: 3500W
    Tamb: -25 to +55°C
    Dims: 472 x 112 x 85 mm
    Fan cooled

  • TET4000 series

    Input: 90-300Vac
    Outputs: 48V dc
    Power: 4000W
    Tamb: 0 to +50°C
    Dims: 530 x 69 x 40.6 mm
    Titanium efficiency / Best in class 98%

  • Aspiro 2U Series

    Input: 85-264Vac
    Outputs: 54V dc nom
    Power: 400 to 4800 Watt
    Tamb: -40 to 75°C
    Dims: 2U x 300mm
    UL / CE EN60950 Approved

  • Guardian 2U24 Series

    Input: 85-264Vac
    Outputs: 27.6V dc nom
    Power: 2000-6000 Watt
    Tamb: -40 to +55°C
    Dims: 1U x 500mm
    UL / CE EN60950 Approved

  • FXP7000 Series

    Input: 200-265Vac
    Outputs: 45.6 to 50.4V
    Power: 7000 Watt
    Tamb: 0 to +70°C
    Dims: 430 x 127 x 203 mm
    UL / CE EN60950 Approved

  • LBC series

    Input: 400-480Vac 3ph
    Outputs: 110V dc
    Power: 8000-12000W
    Tamb: -25 to +85°C
    Dims: 347/406 x 600 x 166 mm
    EN50155 Train borne battery charger

  • Guardian 2U Series

    Input: 85-264Vac
    Outputs: 54V dc nom
    Power: 2000-9000 Watt
    Tamb: -40 to +55°C
    Dims: 2U x 500mm
    UL / CE EN60950 Approved

  • TSR10 series

    Input: 360-440Vac 3ph
    Outputs: 0.5V to 50V dc
    Power: 10000W
    Tamb: +10 to +40°C
    Dims: 480 x 646 x 132.5 (3U) mm

  • TCR-4-48G series

    Input: 180-528Vac 3ph
    Outputs: 28V to 60V dc
    Power: 14000W
    Tamb: 0 to +70°C
    Dims: 3U Subrack, 670mm deep
    Conduction or liquid cooled

  • SPSPFE3 series

    Input: 400-480Vac
    Outputs: 12V dc
    Power: 14400W
    Tamb: 0 to +45°C
    Dims: 47 x 535 x 860mm
    Platinum efficiency / OCP Compatible

  • SPSTET4 series

    Input: , 200-277 / 346-480 VAC
    Outputs: 48V dc
    Power: 19260W
    Tamb: 0 to +45°C
    Dims: 47 x 535 x 600mm
