Non Isolated / POL Converters
Non-isolated / Point of load (POL) converters are the ideal solution for providing tightly regulated voltages of individual ICs, circuits or sub assemblies. We have a range of products optimised for intermediate bus architectures or for wide inputs up to 72V.
Our extensive range of POLs is available in a choice of industry standard footprints and options. Our experts are waiting to find the best solution for you. and there are lots of them
-
K78Lxx-500R3 Series
Input:4.75-36Vdc
Outputs: 3 to 15V dc
Power:1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78_JT-500R3-LB Series
Input: 4.75-36Vdc
Outputs: 3V3 to 15Vdc
Power: 0.75-7.5 Watt
Tamb: -40 to +85°C
Dims: 12 x 12 x 4.5mm (SMD)
Non-isolated -
K78xx-500R3-LB Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78xx-500R3 Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78xxW-500R3 Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3 with flying leads
Non isolated -
K78_JT-500R3 Series
Input: 4.75-36Vdc
Outputs: 3V3 to 15Vdc
Power: 0.75-7.5 Watt
Tamb: -40 to +85°C
Dims: 13.5 x 12.5 x 3.5mm (SMD)
Non isolated -
K78_T-500R3 Series
Input: 4.75-36Vdc
Outputs: 1 to 15Vdc
Power: 0.75-7.5 Watt
Tamb: -40 to +85°C
Dims: SMD10
Non isolated -
K78_MT-500R4 Series
Input: 4.5-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: 9.0 x 7.0mm DFN package
Non isolated -
K78Uxx-500R3 Series
Input: 9.0-90Vdc
Outputs: 3 to 24Vdc
Power: 1.65-12 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78Lxx-1000R3 Series
Input: 6-36Vdc
Outputs: 3 to 15V dc
Power: 3.3-15 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78xx-1000R3 Series
Input: 6-36Vdc
Outputs: 3 to 15V dc
Power: 3.3-15 Watt
Tamb: -40 to +85°C
Dims: SIP3 (90° pins optional)
Non isolated -
K78xxM-1000R3 Series
Input: 6.0-36Vdc
Outputs: 3 to 15V dc
Power: 3.3-15 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78_MT-1000R4 Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 3.30-15 Watt
Tamb: -40 to +85°C
Dims: 9.0 x 7.0mm DFN package
Non isolated -
K78_T-1000R3 Series
Input: 4.75-36Vdc
Outputs: 1 to 15Vdc
Power: 0.75-15 Watt
Tamb: -40 to +85°C
Dims: SMD10
Non isolated -
K78xx-2000R3 Series
Input: 6-36Vdc
Outputs: 3V3 to 15V dc
Power: 6.6-36 Watt
Tamb: -40 to +85°C
Dims: SIP3 (90° pins optional)
Non isolated -
K12T-6A Series
Input: 8.3 - 14Vdc
Outputs: 0.75 to 5V dc
Power: 0-36 Watt
Tamb: -40°C to +85°C
Dims: 20.30 x 11.40 x 6.60mm (SMD)
Non isolated - Industry standard footprint -
K78xx-3AR3 Series
Input: 8 - 36V dc
Outputs: 3.3 - 15V dc
Power: 9.9 - 45 Watt
Tamb: -40 to +85°C
Dims: 32.15 x 14.85 x 9.05 mm
EN62368 approved -
K78Lxx3AR3 Series
Input: 8 - 36V dc
Outputs: 3.3 - 15V dc
Power: 9.9 - 45 Watt
Tamb: -40 to +85°C
Dims: 30.60 x 12.50 x 5.80 mm
EN62368 approved -
K12T-10A/16A Series
Input: 8.3 - 14Vdc
Outputs: 0.75 to 5V dc
Power: 0-90 Watt
Tamb: -40°C to +85°C
Dims: 33.0 x 13.50 x 8.30mm (SMD)
Non isolated - Industry standard footprint -
KUB48 Series
Input: up to 75Vdc
Outputs: 12V to 24V dc
Power: 120/240W
Tamb: -40 to +85°C
Dims: Quarter brick package
Non isolated, Regulated output -
KUB4824CCS Series
Input: 33-72Vdc
Outputs: 24V dc
Power: 250/400 Watt
Tamb: -40°C to +70°C
Dims: 140.00 × 90.00 × 47.00 mm
EN62368-1 Approved -
KUB4836EB Series
Input: 9 to 60V dc
Outputs: 0 - 60V dc (adjustable)
Power: 600W max
Tamb: -40 to +105°C
Dims: Eighth brick package
Non isolated, Regulated output
