Industry: Industrial
Showing 337–352 of 369 results
-
TECS10F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 10-10.8W.
Form Factor: Open frame pcb, 25.4 x 21.1 x 58.5 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS, DEN-AN -
TECS20F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 20-21W.
Form Factor: Open frame pcb, 25.4 x 21.1 x 58.5 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS, DEN-AN -
TECS45F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 40-45W.
Form Factor: Compact enclosed module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TECS65F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 50-66W.
Form Factor: Compact enclosed module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TEPS10F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 10W.
Form Factor: pcb mount, 25.4 x 21.6 x 38.1 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS -
TEPS20F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 20W.
Form Factor: pcb mount, 25.4 x 21.6 x 38.1 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS -
TEPS45F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 40-45W.
Form Factor: PCB-mount module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TEPS65F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 50-66W.
Form Factor: PCB-mount module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TPS300/600 Series
Rated Current: up to 15 A
Rated Voltage: 18-40 V dc
Frequency Range: DC
Leakage Current: N/A
Form Factor: Chassis mount, aluminium baseplate
Certifications: MIL-STD-1275D, DO-160, DEF STAN 61-5, RoHS -
TUNS100F Series
Input Range: 85-264V ac.
Output Range: 5-48V.
Power: 100W.
Form Factor: Half-brick module.
Cooling Method: Baseplate conduction.
Certifications: UL62368-1, EN62368-1, EN60601-1 -
TUNS1200F Series
Input Range: 85-264V ac.
Output Range: 12-48V.
Power: 1200W.
Form Factor: Half-brick module.
Cooling Method: Baseplate conduction.
Certifications: UL62368-1, EN62368-1, EN60601-1 -
TUNS300F Series
Input Range: 85-264V ac.
Output Range: 12-48V.
Power: 300W.
Form Factor: Half-brick module.
Cooling Method: Baseplate conduction.
Certifications: UL62368-1, EN62368-1, EN60601-1 -
TUNS500F Series
Input Range: 85-264V ac.
Output Range: 12-48V.
Power: 500W.
Form Factor: Half-brick module.
Cooling Method: Baseplate conduction.
Certifications: UL62368-1, EN62368-1, EN60601-1 -
TUNS50F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 50W.
Form Factor: quarter-brick module.
Cooling Method: Baseplate conduction.
Certifications: UL62368-1, EN62368-1, EN60601-1 -
TUNS700F Series
Input Range: 85-264V ac.
Output Range: 12-48V.
Power: 700W.
Form Factor: Half-brick module.
Cooling Method: Baseplate conduction.
Certifications: UL62368-1, EN62368-1, EN60601-1 -
UltiMod Series
Input Range: 85-264V ac
Output Range: 1.5V-58V configurable
Power: 600W / 1200W
Form Factor: Modular configurable, 1U Ux4: 260 x 89 x 40 mm / Ux6: 260 x 127 x 40 mm
Cooling Method: Forced air
Certifications: IEC/UL/EN60601-1, IEC/UL/EN62368-1, CE, UKCA, RoHS
