Industry: Industrial
Showing 353–368 of 391 results
-
SR1000T Series
Input Voltage: 18-68 V dc
Output Voltage: 120 / 230 V ac
Power Rating: 1000 W
Form Factor: 19″ 1U Rackmount
Cooling Method: Load-controlled fan
Certifications: UL62368-1, EN62368-1, EN55032, EN55035 -
SW24 Series
Input Range: 28Vac-72Vdc.
Output Range: 24V.
Power: up to 168W.
Form Factor: DIN-rail.
Cooling Method: Free air convection.
Certifications: EN61010-2-201, EMC 2014/30/EU, Low Voltage 2014/35/EU, RoHS -
TCE Series
Input Range: 9-60V dc
Output Range: 56V
Power: 360W
Form Factor: Full-brick
Cooling Method: Baseplate conduction
Certifications: IEC/EN/UL60950-1, MIL-STD-810G -
TCM Series
Input Range: 9-36V dc
Output Range: 12V-28V
Power: 360W
Form Factor: Chassis mount
Cooling Method: Conduction via baseplate
Certifications: Designed to meet UL/cUL 60950, IEC/EN 60950-1, MIL-STD-810G -
TDS-3300 Series
Input Voltage: 400-480 V ac or 600 V dc
Output Voltage: 230 V ac
Power Rating: 3.3 kVA
Form Factor: Slotted chassis module
Cooling Method: Internal forced-air with fan control
Certifications: EN50155, EN45545-2, EN62368-1 -
TDX-3300 Series
Input Voltage: 400-480 V ac or 600 V dc
Output Voltage: 400 V ac
Power Rating: 3.3 kVA
Form Factor: Slotted chassis module
Cooling Method: Internal forced-air with fan control
Certifications: EN50155, EN45545-2, EN62368-1 -
TECS10F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 10-10.8W.
Form Factor: Open frame pcb, 25.4 x 21.1 x 58.5 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS, DEN-AN -
TECS20F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 20-21W.
Form Factor: Open frame pcb, 25.4 x 21.1 x 58.5 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS, DEN-AN -
TECS45F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 40-45W.
Form Factor: Compact enclosed module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TECS65F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 50-66W.
Form Factor: Compact enclosed module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TEPS10F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 10W.
Form Factor: pcb mount, 25.4 x 21.6 x 38.1 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS -
TEPS20F Series
Input Range: 85-264V ac.
Output Range: 5-24V.
Power: 20W.
Form Factor: pcb mount, 25.4 x 21.6 x 38.1 mm.
Cooling Method: Convection / forced air.
Certifications: UL62368-1, EN62368-1, CSA, CE, UKCA, RoHS -
TEPS45F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 40-45W.
Form Factor: PCB-mount module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TEPS65F Series
Input Range: 85-264V ac / 88-370V dc.
Output Range: 3.3-48V.
Power: 50-66W.
Form Factor: PCB-mount module.
Cooling Method: Convection.
Certifications: UL62368-1, EN62368-1, ANSI/AAMI ES60601-1, EN60601-1 -
TPS300/600 Series
Rated Current: up to 15 A
Rated Voltage: 18-40 V dc
Frequency Range: DC
Leakage Current: N/A
Form Factor: Chassis mount, aluminium baseplate
Certifications: MIL-STD-1275D, DO-160, DEF STAN 61-5, RoHS -
TUNS100F Series
Input Range: 85-264V ac.
Output Range: 5-48V.
Power: 100W.
Form Factor: Half-brick module.
Cooling Method: Baseplate conduction.
Certifications: UL62368-1, EN62368-1, EN60601-1
