Power Station Inverter – ODS Series Inverters

“We want an inverter to run our power station control system"


There’s plenty of inverters out there for commercial applications, but not so much choice when it comes to industrial applications.  Our customer was looking for a 230V ac output which could be derived from a 110V dc battery system commonly found in power stations.

  • ODS-750 Series

    Input: 12/24/36/48/72/110Vdc
    Outputs: 120 or 230Vrms ac
    Power: 750 VA
    Tamb: -25 to 70°C
    Dims: 292 x 130 x 49.6mm
    EN62368 / EN50155 Approved


We stock a range of rugged inverters from Premium which are ideal for this application.  We stock products with 24V, 48V and 110V dc inputs as standard.  The ODS series of inverters have a wide operating temperature range and come conformally coated as standard.

  • ODS-1500 Series

    Inputs: 12/24/36/48/72/110Vdc
    Outputs: 120 or 230Vrms ac
    Power: 1500 VA
    Tamb: -25 to 70°C
    Dims: 360 x 160 x 64.5mm
    EN62368 / EN50155 Approved


Speed of response was the essence here.  We could identify the key operating parameters and provide a unit from stock:

  • True sine wave output (THD <2%)
  • RS232 communication
  • Three phase synchronisation
  • -25 to +70 degree operation
  • Ex Stock prototypes
  • Same day technical support
  • Conformal coating
  • Remote on/off
