AEK 3000 HV Series – 3kW of Flexible High Voltage DC Power

26th October 2020

AEK 3000 HV Series – 3kW of Flexible High Voltage DC Power

Outputs from 150V to 400V with built-in redundancy; the AEK 3000 HV Series offers I2C communication and analogue control.

Adaptability is a great asset to have, and the AEK-3000-HV Series of high voltage DC power supplies, is packed full of features making it suitable for any number of applications including undersea power lines, tethered drones, medical imaging, or charging vehicle batteries.

THE FEATURE LIST

AEK 3000 HV Series Banner | 3kW of Flexible High Voltage DC Power | DC Power

The AEK-3000-HV Oring Diode Series is a suite of 3kW AC-DC power supplies with nominal outputs of 150, 200, 250, 300, and 400Vdc.  Each version can have its output voltage and current limit accurately controlled in one of 3 ways;
a) Case mounted potentiometer
b) 0 – 5V control voltage
c) via I2C programming

The true power and flexibility of the AEK-3000 are realized when it used in conjunction with the I2C programming protocol.  The I2C commands for the power supplies can be used to both interrogate and program the power supply in real-time.

The ability to read real-time values such as output voltage & current & internal temperature as well as monitoring alarms for fan failure, over-voltage, and high temperature, make the AEK-3000-HV Series practical for use in live feedback systems.

INDUSTRIES

Industry Applications for the AEK 3000 HV Series | 3kW of Flexible High Voltage DC Power | DC Power

Relec’s technical team are available now to talk you through your application.  The more you can tell us about your requirements and system parameters the better.  Nothing gives us more pleasure than helping our customer’s find the right solution for their application.  Call us today.

Cotek’s AEK-3000-HV Oring Diode Series

AEK-3000-HV Oring Diode Product Image 1

AEK-3000-HV Series

Input: 90 – 264 VAC
Outputs: 150 to 400VDC
Power: 3000 Watt
Tamb: -20 to 60°C
Dims: 280 x 170 x 64mm
EN/UL62368-1 & EN55032 EMC Safety Approved

Other Converters from Cotek
