EUM110A Series
The EUM110A Series is a medical and ITE GaN 100W USB-C charger available with maximum outputs of 85 W or 100 W. Supporting USB Power Delivery 3.0, it provides 5, 9, 12, 15 and 20 Vdc output profiles, with up to 5 A available from the 100 W model. Its universal 100–240 Vac input and selectable C14, C8, C6 or C18 AC inlets support integration into medical, commercial and industrial equipment.
The series provides 2 × MOPP protection and carries IEC/EN 60601-1 medical safety approval alongside IEC/EN 62368-1 certification for ITE applications. It meets Energy Efficiency Level VI requirements and consumes no more than 0.21 W under no-load conditions. Automatic protection covers short circuit, overvoltage and overcurrent conditions, with optional overtemperature protection. Additional features include an LED indicator, an MTBF exceeding 100,000 hours and a compact 136 × 68 × 25.4 mm enclosure.
download the EUM110A Series data sheet
Access detailed specifications, performance data, and technical drawings for the EUM110A Series in our comprehensive datasheet.
Need a 3D drawing?
Our engineers can provide detailed 3D drawings to help you visualise dimensions, mounting, and integration before production.
Stuck on specs? Let’s chat
We’re online and ready to chat.
The EUM110A Series Medical USB-C PD desktop Adaptor
The EUM110A Series is a compact Medical USB-C PD Desktop Adaptor available with outputs of 85 W or 100 W. Supporting USB Power Delivery 3.0, it provides 5, 9, 12, 15 and 20 Vdc output profiles, allowing the connected device and 100W USB-C Charger to negotiate the appropriate voltage.
This GaN Power Supply combines a universal 100–240 Vac input with C14, C8, C6 or C18 AC inlet options. Providing 2 × MOPP protection and IEC/EN 60601-1 medical safety approval, it is suitable for compatible medical, clinical and home healthcare equipment. Level VI efficiency, low no-load power consumption and integrated protection support reliable operation.
