MB2-10ANS

Processor: Intel® Alder Lake-N N97 / i3-N305 Processor
Memory: Up to 16GB
Form Factor: Embedded Fanless
Supports: Display Port, HDMI
Size: 171 x 133 x 57mm
Operating Temperature -25°C to +60°C

Make an Enquiry

Product
First Name*
Last Name*
Email*
Company
Phone
City
Country*
Enquiry*
CAPTCHA
Name
This field is for validation purposes and should be left unchanged.

APPLICATION

The MB2-10ANS is a compact, fanless embedded system powered by Intel® Alder Lake-N processors, available in N97 and i3-N305 configurations. Delivering up to 8 cores and 3.8 GHz performance, it supports DDR5 memory up to 16GB and dual display via HDMI and DisplayPort. Designed for industrial-grade applications, it features a wide 8V–26V DC input, dual 2.5G LAN, multiple USB interfaces including USB Type-C, and robust expansion with M.2 slots for storage, wireless, and AI acceleration via Hailo-8™.

Engineered for durability, it supports operation from -25°C to 60°C with fanless cooling, shock and vibration resistance, and carries CE and FCC Class B certifications. Ideal for edge AI, smart manufacturing, and embedded automation, the MB2-10ANS delivers high performance in a rugged, space-efficient form factor.

feature list

Intel® Alder Lake-N N97 (4C) / i3-N305 (8C8T) Processor
1 x DDR5 SO-DIMM and support up to 16GB
Supports Dual display for HDMI, and DisplayPort
2 x Intel® i226 2.5Gigabit Ethernet
1 x M.2 B Key, 1 x M.2 M Key, 1 x M.2 E Key slot
2 x USB 2.0, 3 x USB 3.2 Gen2 and 1 x USB Type C (with DisplayPort)
8V~26V wide voltage power input
Supports Hailo-8™ AI Accelerator (BTO), up to 26 TOPs

Search:

MODEL NUMBER	CPU	COM / GPIO	AC Adaptor
MB2-10ANS-N97	Intel® Processor N97	2 / None	None
MB2-10ANS-N97-AC	Intel® Processor N97	2 / None	60W AC to DC Adaptor
MB2-10ANS-N305	Intel® Processor i3-N305	4 / 8-bit GPIO	None
MB2-10ANS-N305-AC	Intel® Processor i3-N305	4 / 8-bit GPIO	60W AC to DC Adaptor

Showing 1 to 4 of 4 entries

Downloads

Click on the link below for an instant download.

MB2-10ANS Datasheet
