APPLICATION
The DT200-CS is a high-performance AI-enabled embedded system designed around 8th and 9th Gen Intel® Core™ processors with support for up to 65W TDP in an LGA 1151 socket. Paired with the Q370 or H310 chipset, it supports up to 64GB DDR4 memory and features an MXM 3.1 Type-A/B slot for discrete GPU acceleration up to 115W, making it ideal for edge AI, machine vision, and industrial automation.
This 2U system supports five independent displays (4 DP from MXM, 1 DP++) and offers extensive expansion with three M.2 slots (M, B, and E key), including support for 5G cellular modules. Rich I/O includes 4 GbE LAN ports, 4 USB 3.1 Gen2, 6 USB 2.0, dual COM, and HD audio. The compact 320 x 220 x 87 mm chassis features wall-mount capability and wide connectivity options in a rugged aluminium housing.
With dTPM 2.0 security, fan-based cooling, and support for both Windows 10 IoT and Linux, the DT200-CS is ideal for demanding applications in industrial AI, edge computing, and digital surveillance.
feature list
Supports Intel® Q370 or H310 chipset with up to 65W TDP CPUs
AI acceleration via MXM 3.1 slot (Type A/B) supporting up to 115W GPU modules
Supports five independent displays: 4 DP from MXM and 1 DP++
Scalable expansion with 3 M.2 slots: M key (PCIe Gen3 x4/SATA), B key (PCIe x1/USB 3.1), and E key (PCIe x1/USB 2.0)
Supports 5G communication via M.2 B key 3052 cellular module
4 x Intel Gigabit Ethernet ports (1 x I219LM/V and 3 x I210AT)
Rich I/O with 4 x USB 3.1 Gen2, 6 x USB 2.0, 2 x RS232, Line-out, and Mic-in
Advanced audio with 5.1 channel Realtek ALC888S-VD2-GR codec
TPM 2.0 (dTPM) security module included by default
Wall-mountable, fan-cooled aluminium chassis designed
