iHP Series

iHP Series from Advanced Energy, modular high power ac-dc systems up to 24kW.
Configurable, intelligent and digitally controlled with medical and industrial approvals.

Add to Quote

Add to Compare

Brands: Advanced Energy

download the iHP Series data sheet

Access detailed specifications, performance data, and technical drawings for the iHP Series in our comprehensive datasheet.

View downloads

Need a 3D drawing?

Our engineers can provide detailed 3D drawings to help you visualise dimensions, mounting, and integration before production.

request a drawing

Stuck on specs? Let’s chat

We’re online and ready to chat.

Open chat

APPLICATION

iHP Series from Advanced Energy, modular high power ac-dc systems up to 24kW.
Configurable, intelligent and digitally controlled with medical and industrial approvals.

FEATURES

Input Range 180-660V ac single or 3-phase.

Output Range 0.6-1000V.

Power Up to 24kW per rack.

Form Factor 3U configurable modular system.

Cooling Method Air cooled with smart fans.

Certifications UL62368-1, EN62368-1, IEC60601-1, SEMI F47

INDUSTRY

Broadcast, Industrial, Instrumentation, Medical, Telecom

Model	Input Voltage	Output Voltage	Power Rating
iHP12L1A	180-264V ac 1-phase	12kW	12kW
iHP12L3A	180-264V ac 3-phase	12kW	12kW
iHP12H3A	342-528V ac 3-phase	12kW	12kW
iHP24L3A	180-264V ac 3-phase	24kW	24kW
iHP24H3A	342-528V ac 3-phase	24kW	24kW
iHP24C3A	540-660V ac 3-phase	24kW	24kW
iHP24SH3A	342-528V ac 3-phase	24kW Short Rack	24kW
iHP24SL3A	180-264V ac 3-phase	24kW Short Rack	24kW
SL Module	N/a	12V	2.4kW
SQ Module	N/a	24V	2.88kW
ST Module	N/a	32V	3kW
SW Module	N/a	48V	3kW
S8 Module	N/a	80V	3kW
S1 Module	N/a	125V	3kW
SA Module	N/a	200V	3kW
S2 Module	N/a	250V	3kW
TW Module	N/a	50V	12kW
T3 Module	N/a	300V	12kW
