12.1″ Widescreen HDMI TFT LCD Display
Screen size: 12.1″
Aspect Ratio: 16:10
Active area: 261.12(W) x 163.20(H) mm
Resolution: 1280 x 800
Brightness: 500cd/m2 – 2000cd/m2
Touch Panel Options: PCAP & Resistive
Operating Temperature -30°C to +80°C
Make an Enquiry
The 12.1″ HDMI TFT LCD Display provide a simple method to incorporate a display into equipment. The range all includes an integrated HDMI bridge, LED backlight driver and pre-installed EDID.
The 12.1” HDMI TFT LCD Display range features high brightness levels of up to 2000cd/m2, high contrast ratios and full viewing angle with its IPS technology
The 12.1” HDMI TFT LCD Display range includes a wide variety of brightness options, which makes it suitable for any indoor or outdoor application such as medical, industrial, marine and defence applications. The high brightness, very long LED life time and very wide operating temperature make it an ideal option for harsh environments and mission critical applications.
Further modifications are available on these 12.1″ TFT LCD Display, to enhance the performance. Options include; Optical Bonding, Custom Cover Lens Design, Screen Enhancements, Mounting Frames, Adaptor Boards, Custom Cables and Enhancement Films.
For the Custom Cover Lens Design, this has a variety of options, including custom size, shape and design, apertures for other connections, thick and strengthened glass and custom printing.
Options – customise your display
Brightness options from 480 to 2000cd/m2
IPS Full Viewing Angles
Resolution of 1280 x 800
Low Power Consumption
Operating temperature range -30°C to +80°C
Storage temperature range -30°C to +85°C
Module Supply Voltage: 12 Vdc
Contrast Ratio: 1000
LED Life time: 70,000 hours
|OPERATING TEMP ()||TOUCH|
|HA-121ZILCUAA0-V||HDMI||500||-30 to +80||PCAP|
|HA-121ZILC0GA0-V||HDMI||600||-30 to +80||None|
|HA-121ZILCUAA8-V||HDMI||1800||-30 to +80||PCAP|
|HA-121ZILC0GA8-V||HDMI||2000||-30 to +80||None|
