1.77″ QQVGA TFT LCD Display
Screen size: 1.77″
Aspect Ratio: 5:4
Active area: 28.03(W) x 35.04(H) mm
Resolution: 128 x 160
Interface: MCU 8080 / SPI 3-wire
Touch Panel Options: PCAP & Resistive
Operating Temperature -20°c to +70°C
Make an Enquiry
This 1.77″ TFT LCD Display incorporates a low power backlight design, whilst maintaining a brightness level of 200 cd/m2 and contrast ratio of 500. The operating temperature on this 1.77″ TFT Display is still within industrial grade limits at -20°C to + 70°C.
The small size, low weight and low power requirements on this 1.77″ TFT LCD Display makes it the perfect solution for medical, industrial or any handheld equipment or wearable device applications.
Further modifications are available on this 1.77″ TFT LCD Display, to enhance the performance. Options include; Optical Bonding, Custom Cover Lens Design, Screen Enhancements, Mounting Frames, Adaptor Boards, Custom Cables and Enhancement Films.
For the Custom Cover Lens Design, this has a variety of options, including custom size, shape and design, apertures for other connections, thick and strengthened glass and custom printing.
Options – customise your display
Brightness options from 200cd/m2
Resolution of 128 x 160
Low Power Consumption
MCU 8080 Interface / 3-wire SPI Interface
Operating temperature range -20°C to +70°C
Storage temperature range -30°C to +80°C
Module Supply Voltage: 3.3 Vdc
Anti-glare surface treatment
Viewing direction 12 o'clock (grey inversion)
Contrast Ratio: 500
LED Life time: 20,000 hours
|OPERATING TEMP (°C)||TOUCH|
|13-017FMCB00A0-S||MCU 8080 / 3-wire SPI||200||-20 to +70||None|
