2″ QVGA IPS TFT LCD Display
The 2″ QVGA IPS TFT LCD Display from DigiWise, a compact and efficient colour display module designed for portable and embedded systems.
Combining an IPS panel with a wide viewing angle and MCU interface, it offers excellent clarity and easy integration for small-format applications.
download the 2″ QVGA IPS TFT LCD Display data sheet
Access detailed specifications, performance data, and technical drawings for the 2″ QVGA IPS TFT LCD Display in our comprehensive datasheet.
Need a 3D drawing?
Our engineers can provide detailed 3D drawings to help you visualise dimensions, mounting, and integration before production.
Stuck on specs? Let’s chat
We’re online and ready to chat.
APPLICATION
The 2″ QVGA IPS TFT LCD Display is a 240 x 320 resolution colour active matrix module using amorphous silicon TFT technology. Featuring an IPS, normally black, transmissive display mode, it delivers vivid colour and strong contrast in all directions. The module provides 250 cd/m² typical brightness, 800:1 contrast ratio, and anti-glare surface treatment. It integrates an 8-bit MCU 8080 interface, driven by an ST7789V or compatible controller. With a white LED backlight rated for 20,000 hours, it operates from -20°C to +70°C, making it suitable for handheld, industrial, and embedded devices. Certified to CE, RoHS, and REACH.
