MOOP Power supplies

MOOP or “means of operator protection” is a term which is used within EN60601 to define the safety classification of medical grade power supplies.  Our expert team are here ready talk you through MOOPs and MOPPs and find the best product for your application.

READ MOREREAD LESS
  • FMW-41 Series

    Input: 85 - 264Vac
    Current: 0.5 - 6A
    Tamb: -25°C to +85°C
    Dims: 67 x 46 x 25mm
    Single stage

  • DC12 series

    Input: 85 - 264Vac
    Current: 1 - 10A
    Tamb: -25°C to +85°C
    Dims: C14 Panel inlet filter
    + 1 or 2 pole switch

  • 5500 Series

    Input: 85 - 264Vac
    Current: 1 - 10A
    Tamb: -25°C to +85°C
    Dims: 30.8 x 27.5 x 22.2mm

  • EM1024 Series

    Input: 100-240Vac
    Outputs 5V to 24V
    Power: 36 Watt
    Tamb: 0 to +40°C
    Dims: 100 x 45 x 31mm
    CEC Level VI, EN60601 Compliant

  • FMBB-NEO series

    Input: 85 - 264Vac
    Current: 1 - 36A
    Tamb: -40°C to +100°C
    Dims: Various
    2 stage

  • CFM40M Series

    Input: 90-264Vac
    Outputs 3V3 to 48V
    Power: 40 Watt
    Tamb: -20°C to +70°C
    Dims: 3" x 2" x 0.9"
    EN60601 2xMOPP Approved

  • CFM60M Series

    Input: 90-264Vac
    Outputs 3V3 to 48V
    Power: 60 Watt
    Tamb: -20°C to +70°C
    Dims: 4" x 2" x 1.1"
    EN60601 2xMOPP Approved

  • FMAB-NEO series

    Input: 85 - 264Vac
    Current: 1 - 60A
    Tamb: -40°C to +100°C
    Dims: Various
    Single stage

  • EM1068 Series

    Input: 100-240Vac
    Outputs: 5V to 24V
    Power: 72 Watt
    Tamb: 0 to +40°C
    Dims: 113 x 49 x 35mm
    CEC Level VI & EN60601 Compliant

  • EM1095 Series

    Input: 100-240Vac
    Outputs: 5V to 24V
    Power: 100 Watt
    Tamb: 0 to +40°C
    Dims: 137 x 59 x 34mm
    CEC Level VI & EN60601 Compliant

  • CFM100M Series

    Input: 90-264Vac
    Outputs: 3V3 to 48V
    Power: 100 Watt
    Tamb: -20°C to +70°C
    Dims: 5" x 3" x 1"
    EN60601 2xMOPP Approved

  • CFM130M Series

    Input: 80-264Vac
    Outputs: 12V to 48V
    Power: 130 Watt
    Tamb: 0°C to +70°C
    Dims: 2" x 3" x 1.2"
    UL / CE EN60335-1 Approved

  • EM1170 Series

    Input: 100-240Vac
    Outputs: 12V to 24V
    Power: 180 Watt
    Tamb: 0 to +40°C
    Dims: 179 x 65 x 40mm
    CEC Level VI & EN60601 Compliant

  • CFM200M Series

    Input: 90-264Vac
    Outputs: 3V3 to 48V
    Power: 200 Watt
    Tamb: 0°C to +70°C
    Dims: 4" x 2" x 1.5"
    EN60601 2xMOPP Approved

  • EM1250 Series

    Input: 100-240Vac
    Outputs: 12V to 24V
    Power: 250 Watt
    Tamb: 0 to +40°C
    Dims: 182 x 85 x 46mm
    CEC Level VI & EN60601 Compliant

  • EM1300 Series

    Input: 100-240Vac
    Outputs 12V to 24V
    Power: 300 Watt
    Tamb: 0 to +40°C
    Dims: 197 x 102 x 51mm
    CEC Level VI & EN60601 Compliant

  • CFM300M Series

    Input: 90-264Vac
    Outputs: 3V3 to 48V
    Power: 300 Watt
    Tamb: -40°C to +80°C
    Dims: 5" x 3" x 1.5"
    EN60601 2xMOPP Approved

  • CoolX600 Series

    Input: 85-264Vac
    Outputs: 1 to 4, 2.5 to 58V dc
    Power: 600 Watt
    Tamb: -40°C to +85°C
    Dims: 216 x 114 x 39 mm
    UL / CE EN60950 EN60601 Approved

  • XS1000 Series

    Input: 88-264Vac
    Outputs: 24, 36 or 48V
    Power: 1000 Watt
    Tamb: -40 to +70°C
    Dims: 238 x 126 x 40.60mm
    UL / CE EN60950 EN60601 Approved

  • CoolX1000 Series

    Input: 85-264Vac
    Outputs: 1 to 12, 2.5 to 58V dc
    Power: 1000 Watt
    Tamb: -40°C to +85°C
    Dims: 254 x 165.1 x 39.1 mm
    UL / CE, EN62368-1 EN60601

  • Ultimod Series

    Input: 85-264Vac
    Outputs 1 to 12 - 1.0 to 58V
    Power: 600 / 1200 Watt
    Tamb: -40 to +70°C
    Dims: 280 x 90/127 x 40.4mm
    UL / CE EN60950 EN60601 Approved

  • CoolX1800 Series

    Input: 85-264Vac
    Outputs: 1 to 12, 2.5 to 58V dc
    Power: 1800 Watt
    Tamb: -40°C to +70°C
    Dims: 262 x 127 x 40.6 mm
    UL / CE EN60950, EN62368-1 EN60601

  • CoolX3000 Series

    Input: 85-264Vac
    Outputs: 1 to 24, 2.5 to 58V dc
    Power: 3000 Watt
    Tamb: -40°C to +60°C
    Dims: 300 x 131 x 120 mm
    UL / EN62368-1 EN60601 (2xMOPP)
