DIN rail mounted power supplies offer a simple, uncomplicated method of integrating power conversion to both equipment and installations.
Typical applications include process control panels, machinery, building automation, outdoor telemetry, ticketing machines and network security equipment.
We carry extensive stocks for next day delivery, but we are more than happy to customise and schedule to your requirements. Let us have as much application information as possible and we will take care of the rest based on price, reliability and availability.
-
AMR1 Series
Input: 90-264Vac
Outputs: 5V to 24V
Power: 10 Watt
Tamb: -40 to 71°C
Dims: 91 x 56.5 x 18mm
UL / CE EN62368-1 Approved -
DRA18 Series
Input: 90-264Vac
Outputs: 5V to 24Vdc
Power: 18 Watt
Tamb: -25 to 71°C
Dims: 90 x 114 x 22.5mm
UL / CE EN62368-1 Approved -
DFX15 Series
Input range: 85-305Vac
Outputs: 12V to 24V
Power: 20 Watt
Tamb: -25 to 70°C
Dims: 18 x 90 x 55mm
Made in Italy -
AMR2 Series
Input: 90-264Vac
Outputs: 5V to 24V
Power: 24 Watt
Tamb: -40 to 71°C
Dims: 91 x 56.5 x 35mm
UL / CE EN62368-1 Approved -
DRAN30 Series
Input: 85-264Vac
Outputs: 5V to 48Vdc
Power: 30 Watt
Tamb: -40 to 71°C
Dims: 90 x 114 x 40.5mm
UL / CE EN62368-1 Approved -
FLEX60 Series
Input range: 115 to 230Vac
Outputs: 5V
Power: 25W (35W peak)
Tamb: -25 to 70°C
Dims: 50 x 120 x 50mm
Made in Italy -
AMR3 Series
Input: 90-264Vac
Outputs: 5V to 24V
Power: 36 Watt
Tamb: -40 to 71°C
Dims: 91 x 56.5 x 53mm
UL / CE EN62368-1 Approved -
CBI123A Series
Input range: 90 to 305Vac
Outputs 12Vdc – 3A to 9A (With battery)
Power: 36 Watt (Charge)
Tamb: -25 to 70°C
Dims: 135 x 115 x 65mm
Approved to EN62368-1
Made in Italy -
DRAN60 Series
Input: 85-264Vac
Outputs: 5V to 48Vdc
Power: 60 Watt
Tamb: -40 to 71°C
Dims: 90 x 114 x 40.5mm
UL / CE EN62368-1 Approved -
CB6012A Series
Input range: 90 to 277Vac
Outputs 14.1 or 14.5Vdc – 5A
Power: 60 Watt (nom)
Tamb: -25 to 70°C
Dims: 72 x 90 x 61mm
Approved to IEC/EN 62368-1, IEC/EN 61000-6-3, IEC/EN 61000-6-2
Made in Italy -
DRU30 Series
Input: 12 or 24V dc
Outputs 13.6 or 27.2V dc
Power: 60 Watt (Charge)
Tamb: -40 to 71°C
Dims: 90 x 114 x 54mm
UL / CE EN60950 Approved -
AMR4 Series
Input: 90-264Vac
Outputs: 5V to 24V
Power: 60 Watt
Tamb: -40 to 71°C
Dims: 91 x 56.5 x 71mm
UL / CE EN62368-1 Approved -
DBR Series
Input: 90-264Vac
Outputs 13.6 or 27.2V dc
Power: 60 Watt (Charge)
Tamb: -40 to 51°C
Dims: 91 x 56.5 x 90mm
UL / CE EN62368-1 Approved -
DFX60 Series
Input range: 85-305Vac
Outputs: 12V to 24V
Power: 65 Watt
Tamb: -25 to 70°C
Dims: 54 x 90 x 55mm
Made in Italy -
CBI243A Series
Input: 90 to 305Vac
Outputs: 24Vdc – 3A
Power: 72 Watt
Tamb: -25 to 71°C
Dims: 65 x 115 x 135 mm
Approvals: EN62368-1
Made in Italy -
CB6024A Series
Input range: 90 to 277Vac
Outputs 28.2 or 29.0Vdc – 3A (5A max)
Power: 72 Watt (nom)
Tamb: -25 to 70°C
Dims: 72 x 90 x 61mm
Approved to IEC/EN 62368-1, IEC/EN 61000-6-3, IEC/EN 61000-6-2
Made in Italy -
DRA100 Series
Input: 90-264Vac
Outputs: 12V to 48V
Power: 100 Watt
Tamb: -35 to 71°C
Dims: 90 x 114 x 54mm
UL / CE EN62368-1 Approved -
AMR5 Series
Input: 90-264Vac
Outputs: 5V to 24V
Power: 100 Watt
Tamb: -40 to 71°C
Dims: 91 x 56.5 x 90mm
UL / CE EN62368-1 Approved -
CBI126A Series
Input range: 90 to 305Vac
Outputs 12Vdc – 6A to 18A (With battery)
Power: 72 Watt (Charge)
Tamb: -25 to 70°C
Dims: 135 x 115 x 65mm
Approvals: EN62368-1
Made in Italy -
CBI1210A Series
Input: 90 – 305Vac
Outputs 12Vdc – 10A
Power: 120 Watt (Charge)
Tamb: -25 to 71°C
Dims: 135 x 115 x 65mm
Approvals: EN62368-1
Made in Italy -
DRAN120 Series
Input: 115/230Vac (auto select)
Outputs: 12V to 48Vdc
Power: 120 Watt
Tamb: -40 to 71°C
Dims: 124 x 116 x 64mm
UL / CE EN62368-1 Approved -
CBI245A Series
Input: 90 to 305Vac
Outputs: 24Vdc – 5A
Power: 120 Watt
Tamb: -25 to 71°C
Dims: 65 x 115 x 135 mm
Approvals: EN62368-1
Made in Italy -
DRE120 Series
Input: 88-264Vac
Outputs: 12V to 24V
Power: 120-180 Watt
Tamb: -40 to 71°C
Dims: 124 x 116 x 40mm
UL / CE EN62368-1 Approved -
FLEX170 Series
Single-phase I/P: 115/230Vac (Manual select)
Three-phase Input range: 330-550Vac
Outputs: 12V to 48V
Power: 170 Watt
Tamb: -25 to 70°C
Dims: 50 x 120 x 50mm
Made in Italy -
CBI2801224A Series
Input: 90 – 135V ac / 180 – 305V ac
Outputs: 10 – 14.4V dc / 22 – 28.8V dc
Power: 180 / 240 Watt (Charge)
Tamb: -25 to 71°C
Dims: 100 x 115 x 135 mm
Approvals: EN62368-1
Made in Italy -
DRA240 Series
Input: 115/230Vac (auto select)
Outputs: 24V or 48V
Power: 240 Watt
Tamb: -40 to 71°C
Dims: 124 x 116 x 83.5mm
UL / CE EN62368-1 Approved -
CBI2410A Series
Input: 90 to 135/180 to 305Vac
Outputs 24Vdc – 10A
Power: 240 Watt (Charge)
Tamb: -25 to 71°C
Dims: 135 x 115 x 100 mm
Approvals: EN62368-1
Made in Italy -
CBI485A Series
Input: 90 to 135/180 to 305Vac
Outputs 48Vdc – 5A
Power: 240 Watt (Charge)
Tamb: -25 to 71°C
Dims: 135 x 115 x 100 mm
Approvals: EN62368-1
Made in Italy -
DRE240 Series
Input: 88-264Vac
Outputs: 12V to 24V
Power: 240-360 Watt
Tamb: -40 to 71°C
Dims: 124 x 116 x 64mm
UL / CE EN62368-1 Approved -
CB2410AC Series
Input: 115 to 227Vac
Output: 27.5 to 28.8Vdc – 10A
Power: 240 Watt (Charge)
Tamb: -25 to 70°C
Dims: 100 x 115 x 135 mm
Conforms to: IEC/EN 60335-2-29, EN60950 / UL60950-1, EN54-4 (fire detection)
Made in Italy -
DRP10 Series
Input: 9-35Vdc
Outputs Vin -0.5V @ 10A
Power: 240 Watt
Tamb: -40 to 71°C
Dims: 91 x 56.5 x 35mm
Redundancy Module -
DRA300 Series
Input: 115/230Vac (auto select)
Outputs: 24V or 48Vdc
Power: 300 Watt
Tamb: -30 to 71°C
Dims: 124 x 116 x 83.5mm
UL / CE EN62368-1 Approved -
FLEX280 Series
Single-phase I/P: 115/230Vac (Manual select)
Three-phase Input range: 330-550Vac
Outputs: 12V to 48V
Power: Up to 336 Watt
Tamb: -25 to 70°C
Dims: 72 x 115 x 135 mm
Made in Italy -
CBI1235A Series
Input: 90 to 135/180 to 305Vac
Outputs: 12Vdc 35A
Power: 420 Watt
Tamb: -25 to 71°C
Dims: 150 x 115 x 135 mm
Approvals: EN62368-1
Made in Italy -
DRA480 Series
Input: 90-264Vac
Outputs: 24V or 48Vdc
Power: 480 Watt
Tamb: -40 to 71°C
Dims: 175 x 116 x 83.5mm
UL / CE EN62368-1 Approved -
DRE480 Series
Input: 88-264Vac
Outputs: 24V to 48V
Power: 480-720 Watt
Tamb: -40 to 71°C
Dims: 124 x 116 x 83.5mm
UL / CE EN62368-1 Approved -
DRP20 Series
Input: 9-35Vdc
Outputs Vin -0.5V @ 20A
Power: 480 Watt
Tamb: -40 to 71°C
Dims: 114 x 90 x 54mm
Redundancy Module -
CBI2420A Series
Input: 90 to 135/180 to 305Vac
Outputs 24Vdc – 20A
Power: 500 Watt (Charge)
Tamb: -25 to 71°C
Dims: 150 x 115 x 135 mm
Approvals: EN62368-1
Made in Italy -
CBI4810A Series
Input: 115 to 277Vac
Outputs 48Vdc – 10A
Power: 500 Watt (Charge)
Tamb: -25 to 71°C
Dims: 150 x 115 x 135 mm
Approvals: EN62368-1
Made in Italy -
FLEX500 Series
Single-phase I/P: 115/230Vac (Manual select)
Three-phase Input range: 330-550Vac
Outputs: 24V to 48V
Power: Up to 600 Watt
Tamb: -25 to 70°C
Dims: 85 x 120 x 140 mm
Made in Italy -
FDS-3K Series
Input: 90 - 265Vac
Outputs: 125Vdc
Power: 3000W
Tamb: -10°C to +60°C
Made in Spain
