Instrumentation Grade Power Supplies
Relec Electronics have a large range of PCB and External (Plugtop & Desktop) AC DC & DC DC Converters suitable for Instrumentation applications. Products start at 1W with solutions available through to 300W. Many of the products listed below are available from stock and we are always happy to supply free of charge samples for new projects – Call us today on +44 1929 555800 for more information.
-
LH05 Series
Input: 85-264Vac
Outputs 3V3 to 24V
Power: 5 Watt
Tamb: -25 to 70°C
Dims: 48.5 x 36 x 20.5mm
UL / CE EN60950 Approved -
LS05-26B Series
Input: 90-528Vac
Outputs 3V3 to 24V
Power: 5 Watt
Tamb: -40 to 85°C
Dims: 44.5 x 13 x 24.0mm
UL / CE EN62368 -
LS05 K3 Series
Input: 85-305Vac
Outputs 12V, 15V & 18Vdc
Power: 5 Watts
Tamb: -40 to 85°C
Dims: 16.13 x 18.17 x 9.50 mm
EN/UKCA 62368 Safety Approved
Non Isolated -
5008 series
Input: 85 - 264Vac
Current: 0.5 - 6A
Tamb: -25°C to +85°C
Dims: C8 Panel inlet filter
-
FMW-41 Series
Input: 85 - 264Vac
Current: 0.5 - 6A
Tamb: -25°C to +85°C
Dims: 67 x 46 x 25mm
Single stage
-
D Series
Input:15V dc
Outputs: up to 6kVdc
Power: up to 6 Watt
Tamb: -10°C to +65°C
Dims: 63.5 x 44 x 17.5mm -
CVRC_JD-6WR3 Series
Input: 9-18V dc
Outputs 3 x 15V dc
Power: 6 Watt
Tamb: -40°C to +105°C
Dims: 43.60 x 25.00 x 10.50mm
AEC-Q100 for automotive applications -
CUWB_YMD-6WR3 Series
Input: 4.5-36V dc
Outputs 3V to 24V dc
Power: 6 Watt
Tamb: -40 to +105°C
Dims: 1" x 1" x 0.465"
AEC-Q100 for automotive applications -
CUWF_J(Y)T-6WR3 Series
Input: 6-42V dc
Outputs 5V to 24V dc
Power: 6 Watt
Tamb: -40 to +105°C
Dims: 44.5 x 25.0mm
Meets IATF16949 production standards -
K78_T-500R3 Series
Input: 4.75-36Vdc
Outputs: 1 to 15Vdc
Power: 0.75-7.5 Watt
Tamb: -40 to +85°C
Dims: SMD10
Non isolated -
K78Lxx-500R3 Series
Input:4.75-36Vdc
Outputs: 3 to 15V dc
Power:1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78xxW-500R3 Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3 with flying leads
Non isolated -
K78xx-500R3 Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78_JT-500R3 Series
Input: 4.75-36Vdc
Outputs: 3V3 to 15Vdc
Power: 0.75-7.5 Watt
Tamb: -40 to +85°C
Dims: 13.5 x 12.5 x 3.5mm (SMD)
Non isolated -
K78_JT-500R3-LB Series
Input: 4.75-36Vdc
Outputs: 3V3 to 15Vdc
Power: 0.75-7.5 Watt
Tamb: -40 to +85°C
Dims: 12 x 12 x 4.5mm (SMD)
Non-isolated -
K78xx-500R3-LB Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78_MT-500R4 Series
Input: 4.5-36Vdc
Outputs: 3 to 15V dc
Power: 1.65-7.5 Watt
Tamb: -40 to +85°C
Dims: 9.0 x 7.0mm DFN package
Non isolated -
LS08 Series
Input: 85-305Vac
Outputs 3V3 to 24V
Power: 8 Watt
Tamb: -40 to 85°C
Dims: 44.5 x 15.0 x 22.45mm
UL / CE EN62368 Approved -
5500 Series
Input: 85 - 264Vac
Current: 1 - 10A
Tamb: -25°C to +85°C
Dims: 30.8 x 27.5 x 22.2mm
-
LD10 R2-M Series
Input: 85 - 305V ac / 100 - 430V dc
Outputs: 3.3 - 24V dc
Power: 10 Watt
Tamb: -40 to +85°C
Dims: 47.60 x 26.80 x 23.50 mm
Designed to meet IEC/UL62368/EN60335/EN61558
EN/UL/CE EN62368 Approved -
EC7AW18-72 Series
Input: 8.5-160V dc- Single range
Outputs: 5V to +/-15V dc
Power: 10 Watt
Tamb: -40°C to +100°C
Dims: 31.8 x 20.3 x 12.7mm (DIP24)
3000V ac Isolation -
LD10 Series
Input: 85-264Vac
Outputs: 3V3 to 24V
Power: 10 Watt
Tamb: -25 to +70°C
Dims: 53.8 x 28.8 x 19mm
UL / CE EN60950 Approved -
LH10 Series
Input: 85-264Vac
Outputs 3V3 to 24V
Power: 10 Watt
Tamb: -40 to 70°C
Dims: 55 x 45 x 21mm
UL / CE EN60950 Approved -
EC5DAW Series
Input: 9-74VDC
Outputs: 3.3VDC to ±15VDC
Power: 10 Watt
Tamb: -40°C to +105°C
Dims: 24.13 x 13.72 x 9.91mm (DIP24)
3000VDC Isolation -
5200 Series
Input: 85 - 264Vac
Current: 1 - 10A
Tamb: -25°C to +85°C
Dims: C14 Panel inlet filter
+ single pole fuseholder
-
LS10 Series
Input: 85-305Vac
Outputs 3V3 to 24V
Power: 10 Watt
Tamb: -40 to 85°C
Dims: 44.5 x 15.0 x 22.45mm
UL / CE EN62368 Approved -
LS10 R3 Series
Input: 85-305Vac
Outputs 3.3V to 24V
Power: 10 Watts
Tamb: -40 to 85°C
Dims: 32.00 x 17.20 x 15.05 mm
IEC/EN/UL62368 Approved -
DC12 series
Input: 85 - 264Vac
Current: 1 - 10A
Tamb: -25°C to +85°C
Dims: C14 Panel inlet filter
+ 1 or 2 pole switch
-
LD10 R2 Series
Input: 85-305Vac
Outputs: 3.3V to 24V
Power: 10 Watts
Tamb: -40 to +85°C
Dims: 40 x 25.5 x 21mm
EN/UL/CE EN62368/60335/61558 Approved -
K78Uxx-500 Series
Input: 9.0-72Vdc
Outputs: 3 to 24Vdc
Power: 1.65-12 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78Uxx-500R3 Series
Input: 9.0-90Vdc
Outputs: 3 to 24Vdc
Power: 1.65-12 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78xx-2000 Series
Input: 4.75-18Vdc
Outputs: 1.5 to 12V dc
Power: 3-13 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
LD15 R2-M Series
Input: 85 - 305V ac / 100 - 430V dc
Outputs: 3.3 - 24V dc
Power: 13.2 - 15 Watt
Tamb: -40 to +85°C
Dims: 52.40 x 27.20 x 24.00 mm
Designed to meet IEC/UL62368/EN60335/EN61558
EN/UL/CE EN62368 Approved -
LHE15-R2 Series
Input: 85-305Vac
Outputs 3V3 to 48V
Power: 15 Watt
Tamb: -40 to 85°C
Dims: 62 x 45 x 22.5mm
UL / CE EN62368 Approved -
LH15 Series
Input: 85-264Vac
Outputs: 3V3 to 24Vdc
Power: 15 Watt
Tamb: -40 to 70°C
Dims: 62 x 45 x 22.5mm
UL / CE EN60950 Approved -
LS15 Series
Input: 85-305Vac
Outputs 3V3 to 24V
Power: 15 Watt
Tamb: -40 to 85°C
Dims: 44.5 x 15.0 x 22.45mm
Designed to meet UL / CE EN62368 -
LD15 R2 Series
Input: 85-305Vac
Outputs: 3.3V to 24V
Power: 15 Watts
Tamb: -40 to +85°C
Dims: 47.6 x 26.8 x 23.5mm
EN/UL/CE EN62368/60335/61558 Approved -
K78_T-1000R3 Series
Input: 4.75-36Vdc
Outputs: 1 to 15Vdc
Power: 0.75-15 Watt
Tamb: -40 to +85°C
Dims: SMD10
Non isolated -
K78Lxx-1000R3 Series
Input: 6-36Vdc
Outputs: 3 to 15V dc
Power: 3.3-15 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78xx-1000R3 Series
Input: 6-36Vdc
Outputs: 3 to 15V dc
Power: 3.3-15 Watt
Tamb: -40 to +85°C
Dims: SIP3 (90° pins optional)
Non isolated -
K78xxM-1000R3 Series
Input: 6.0-36Vdc
Outputs: 3 to 15V dc
Power: 3.3-15 Watt
Tamb: -40 to +85°C
Dims: SIP3
Non isolated -
K78_MT-1000R4 Series
Input: 4.75-36Vdc
Outputs: 3 to 15V dc
Power: 3.30-15 Watt
Tamb: -40 to +85°C
Dims: 9.0 x 7.0mm DFN package
Non isolated -
EC7BW18-72 Series
Input: 8.5-160V dc- Single range
Outputs: 5V to +/-24V dc
Power: 20 Watt
Tamb: -40°C to +105°C
Dims: 2.0" x 1.0" x 0.4"
3000V ac Isolation -
URA_YMD-20WR3 Series
Input: 9-36V or 18-75V dc
Outputs ±5V to ±24V dc
Power: 20 Watt
Tamb: -40 to +85°C
Dims: 1" x 1"
1500V Isolation -
EC7BW18 ECRT/EDRT Series
Input: 10-160V dc- Single range
Outputs: 5V to +/-24V dc
Power: 20 Watt
Tamb: -40°C to +100°C
Dims: 4.45" x 2.33" x 0.68" (113 x 59.2 x 21.6mm)
3000V ac Isolation -
LD20 Series
Input: 85-264Vac
Outputs: 3V3 to 24Vdc
Power: 20 Watt
Tamb: -25 to +70°C
Dims: 50.8 x 25.4 x 15.16mm
UL / CE EN60950 Approved
-
LH20 Series
Input: 85-264Vac
Outputs: 3V3 to 24Vdc
Power: 20 Watt
Tamb: -40 to 70°C
Dims: 70 x 48 x 23.5mm
UL / CE EN60950 Approved -
C20F Series
Input: 85 - 264Vac
Current: 16 - 20A
Tamb: -25°C to +85°C
Dims: C20 Panel inlet filter -
LD20 R2 Series
Input: 85-305Vac
Outputs: 3.3V to 24V
Power: 20 Watts
Tamb: -40 to +85°C
Dims: 52.4 x 27.2 x 24.00mm
EN/UL/CE EN62368/60335/61558 Approved -
LHE25 Series
Input: 85-264Vac
Outputs 3V3 to 24V
Power: 25 Watt
Tamb: -40 to 85°C
Dims: 70 x 48 x 23.5mm
UL / CE EN62368 Approved -
LM25-23Bxx Series
Input: 85 - 305Vac
Outputs: 5 to 24Vdc
Power: 25 Watt
Tamb: -30 to +70°C
Dims: 80 x 55 x 20mm
IEC/UL/EN62368 Approved
Very low cost -
CFM25S Series
Input: 90-264Vac
Outputs: 5V to 48V
Power: 25 /50 Watt (<10 Secs)
Tamb: -30°C to +80°C
Dims: 2" x 1.1" x 1.0"
UL / CE EN62368 Approved -
LH25-23BxxR2 Series
Input: 85-305Vac or 100-430Vdc
Outputs 13.53W to 26.4W
Power: 25 Watt
Tamb: -40 to 85°C
Dims: 70 x 48 x 23.5mm
IEC/EN61000-4, CISPR32/EN55032, IEC/EN/UL62368 Approved -
LH25 Series
Input: 85-264Vac
Outputs 3V3 to 24V
Power: 25 Watt
Tamb: -40 to 70°C
Dims: 70 x 48 x 23.5mm
UL / CE EN60950/60601 Approved -
K78xx-2000R3 Series
Input: 6-36Vdc
Outputs: 3V3 to 15V dc
Power: 6.6-36 Watt
Tamb: -40 to +85°C
Dims: SIP3 (90° pins optional)
Non isolated -
E Series
Input:23 to 30V dc
Outputs: 0 to 15kV dc
Power: 30 Watt
Tamb: +10°C to +45°C
Dims: 152.4 x 96.8 x 38.1mm -
LO30-20BxxMU Series
Input: 80 - 264VAC / 100 - 370VDC
Outputs: 3V3 to 48V
Power: 30 Watts
Tamb: -30°C to +85°C
Dims: 76.20 x 50.80 x 26.50mm (3" x 2" x 1.04")
Medical & ITE Approvals (EN60601 2xMOPP, UL/EN62368-1 EN60335 Approved)
3 Year Warranty -
AA Series
Input: 12V or 24V dc
Outputs: 1kV to 6kV
Power: up to 30 Watt
Tamb: -40°C to +65°C
Dims: 75.4 x 38.1 x 19.1mm -
A Series
Input:12V dc
Outputs: up to 40kV
Power: up to 30 Watt
Tamb: -40°C to +65°C
Dims: 94 x 38.1 x 19.6mm -
LD30 R2 Series
Input: 85-305Vac
Outputs: 3.3V to 24V
Power: 30 Watts
Tamb: -40 to +85°C
Dims: 69.5 x 39.00 x 24.00mm
EN/UL/CE EN62368/60335/61558 Approved -
LM35-23Bxx Series
Input: 85 - 305Vac
Outputs: 5 to 24Vdc
Power: 35 Watt
Tamb: -30 to +70°C
Dims: 99 x 82 x 30mm
IEC/UL/EN62368 Approved
Very low cost -
K12T-6A Series
Input: 8.3 - 14Vdc
Outputs: 0.75 to 5V dc
Power: 0-36 Watt
Tamb: -40°C to +85°C
Dims: 20.30 x 11.40 x 6.60mm (SMD)
Non isolated - Industry standard footprint -
CBI123A Series
Input range: 90 to 305Vac
Outputs 12Vdc – 3A to 9A (With battery)
Power: 36 Watt (Charge)
Tamb: -25 to 70°C
Dims: 135 x 115 x 65mm
Approved to EN62368-1 -
EA1024 Series
Input: 100-240Vac
Outputs 5V to 24V
Power: 36 Watt
Tamb: 0 to +40°C
Dims: 100 x 45 x 31mm
CEC Level VI/EN/IEC/UL62368-1 approved -
NCM Series
Input: 9-18, 18-36 or 36-75VDC
Outputs: 2.7-15VDC
Power: 40 Watt
Tamb: -40 to 100˚C
Dims: 67.31 x 109.22 x 25.4mm
RoHS Compliant -
LHE40 Series
Input: 85-264Vac
Outputs 3V3 to 48V
Power: 40 Watt
Tamb: -40 to 70°C
Dims: 89 x 63.5 x 25.0mm
UL / CE EN62368 Approved -
ECLB-40W Series
Input: 9-36V or 18-75V dc
Outputs: 3V to +/-15V dc
Power: 40 Watt
Tamb: -40°C to +105°C
Dims: 2.05" x 1.2" x 0.4"
1500V dc Isolation -
LH40 Series
Input: 85-264Vac
Outputs 3V3 to 24Vdc
Power: 40 Watt
Tamb: -40 to 70°C
Dims: 89 x 63.50 x 25mm
UL / CE EN60950 Approved -
LD40-23BxxR2 Series
Input: 85-305Vac
Outputs: 5V to 48V
Power: 40 Watts
Tamb: -40 to +85°C
Dims: 69.5 x 39.00 x 24.00mm
EN/UL/CE EN62368/60335/61558/62477/55032/61000-4 Approved -
CFM41S Series
Input: 90-264Vac
Outputs: 5V to 48V
Power: 40 / 80 Watt (< 10 Secs)
Tamb: -30°C to +80°C
Dims: 2" x 2" x 1.0"
UL / CE EN62368 Approved -
SCM1101 Series
Input: 0 to 23V dc
Outputs: Any (Transformer dependent)
Power: 5 to 40 Watt
Tamb: -40°C to +125°C
Dims: MSOP-8
Highly integrated PWM controller
-
K78xx-3AR3 Series
Input: 8 - 36V dc
Outputs: 3.3 - 15V dc
Power: 9.9 - 45 Watt
Tamb: -40 to +85°C
Dims: 32.15 x 14.85 x 9.05 mm
EN62368 approved -
K78Lxx3AR3 Series
Input: 8 - 36V dc
Outputs: 3.3 - 15V dc
Power: 9.9 - 45 Watt
Tamb: -40 to +85°C
Dims: 30.60 x 12.50 x 5.80 mm
EN62368 approved -
LDE45 Series
Input: 85-264Vac
Outputs: 5V to 48Vdc
Power: 45 Watt
Tamb: -40 to +70°C
Dims: 87.00 x 52.00 x 29.5mm
EN62368 Approved -
LO45-20BxxSMU Series
Input: 80 - 264VAC / 100 - 370VDC
Outputs: 3V3 to 48V
Power: 45 Watts
Tamb: -40°C to +85°C
Dims: 76.20 x 50.80 x 26.50mm (3" x 2" x 1.03")
Medical & ITE Approvals (EN60601 2xMOPP, UL/EN62368-1 EN60335 Approved)
5 Year Warranty -
EA1045 Series
Input: 100-240Vac
Outputs: USB-C Power Delivery (5 - 20Vdc)
Power: 30 - 45 Watts
Tamb: 0 to +40°C
Dims: 100 x 45 x 31mm
UL/cUL 62368-1 TUV EN62368-1, CB IEC 62368-1, FCC, CE -
LM50-23Bxx Series
Input: 85 - 305Vac
Outputs: 5 to 24Vdc
Power: 50 Watt
Tamb: -30 to +70°C
Dims: 99 x 82 x 30mm
IEC/UL/EN62368 Approved
Very low cost -
LHE60 Series
Input: 85-264Vac
Outputs 5V to 48V
Power: 60 Watt
Tamb: -40 to 70°C
Dims: 109 x 58.5 x 30.0mm
UL / CE EN62368 Approved -
CB6012A Series
Input range: 90 to 277Vac
Outputs 14.1 or 14.5Vdc – 5A
Power: 60 Watt (nom)
Tamb: -25 to 70°C
Dims: 72 x 90 x 61mm
Approved to IEC/EN 62368-1, IEC/EN 61000-6-3, IEC/EN 61000-6-2 -
ECLB-60W Series
Input: 9-36V or 18-75V dc
Outputs: 3V to +/-15V dc
Power: 60 Watt
Tamb: -40°C to +105°C
Dims: 2.05" x 1.2" x 0.4"
1500V dc Isolation -
LDE60 Series
Input: 85-264Vac
Outputs: 5V to 48Vdc
Power: 60 Watt
Tamb: -40 to +70°C
Dims: 87.00 x 52.00 x 29.5mm
EN62368 Approved -
LH60 Series
Input: 85-264Vac (55 - 264 DT)
Outputs 3V3 to 24Vdc
Power: 60 Watt
Tamb: -40 to 70°C
Dims: 109 x 58.50 x 30mm
UL / CE EN60950 Approved -
LD60-23BxxR2 Series
Input: 85-305Vac
Outputs: 5V to 48V
Power: 60 Watts
Tamb: -40 to +85°C
Dims: 70.00 x 48.00 x 27.00mm
EN/UL/CE EN62368/60335/61558/62477/55032/61000-4 Approved -
EA1062 Series
Input: 100-240Vac
Outputs: USB-C Power Delivery (5 - 20Vdc)
Power: 60 Watts max
Tamb: 0 to +40°C
Dims: 113 x 47.5W x 31H (mm)
UL/cUL 62368-1 TUV EN62368-1, CB IEC 62368-1, FCC, CE -
LO65-20BxxSMU Series
Input: 80 - 264VAC / 100 - 370VDC
Outputs: 3V3 to 48V
Power: 65 Watts
Tamb: -40°C to +85°C
Dims: 76.20 x 50.80 x 26.50mm (3" x 2" x 1.03")
Medical & ITE Approvals (EN60601 2xMOPP, UL/EN62368-1 EN60335 Approved)
5 Year Warranty -
EA1068 Series
Input: 100-240Vac
Outputs: 5V to 24V
Power: 72 Watt
Tamb: 0 to +40°C
Dims: 113 x 49 x 35mm
CEC Level VI/EN/IEC/UL62368-1 approved -
CB6024A Series
Input range: 90 to 277Vac
Outputs 28.2 or 29.0Vdc – 3A (5A max)
Power: 72 Watt (nom)
Tamb: -25 to 70°C
Dims: 72 x 90 x 61mm
Approved to IEC/EN 62368-1, IEC/EN 61000-6-3, IEC/EN 61000-6-2 -
CBI243A Series
Input: 90 to 305Vac
Outputs: 24Vdc – 3A
Power: 72 Watt
Tamb: -25 to 71°C
Dims: 65 x 115 x 135 mm
Approvals: EN62368-1 -
ECLB-75W Series
Input: 9-36V or 18-75V dc
Outputs: 3V to +/-15V dc
Power: 75 Watt
Tamb: -40°C to +105°C
Dims: 2.05" x 1.2" x 0.4"
1500V dc Isolation -
QCM Series
Input: 18-36 or 36-75VDC
Outputs: 3.3-24VDC
Power: 75 Watt
Tamb: -40 to 100˚C
Dims: 67.31 x 106.68 x 25.4mm
5 Year Warranty -
CQB75-300S Series
Input: 180 to 425V dc
Outputs: 5V to 48V dc
Power: 75 Watt
Tamb: -40°C to +105°C
Dims: Quarter Brick
3000V AC Reinforced Isolation -
AIQ00ZPFC Series
Input: 100 - 122Vac
Outputs: 393Vdc
Power: 75 Watts
Temp: -20 to 100˚C
Dims: 57x37x13.95mm (2.3x1.45 x 0.5")
UL / CE Approved
1 Year Warranty -
LM75-23Bxx Series
Input: 85 - 305Vac
Outputs: 5 to 24Vdc
Power: 75 Watt
Tamb: -30 to +70°C
Dims: 99 x 97 x 30mm
IEC/UL/EN62368 Approved
Very low cost -
K12T-10A/16A Series
Input: 8.3 - 14Vdc
Outputs: 0.75 to 5V dc
Power: 0-90 Watt
Tamb: -40°C to +85°C
Dims: 33.0 x 13.50 x 8.30mm (SMD)
Non isolated - Industry standard footprint -
LD90-23BxxR2 Series
Input: 80-305Vac
Outputs: 12V to 48V
Power: 90 Watts
Tamb: -40 to +85°C
Dims: 87.00 x 52.00 x 29.50mm
IEC/EN61000-4, CISPR32/EN55032, UL/IEC/EN/BS EN62368, IEC/EN60335/61558 Approved -
EA1095 Series
Input: 100-240Vac
Outputs: 5V to 24V
Power: 100 Watt
Tamb: 0 to +40°C
Dims: 137 x 59 x 34mm
CEC Level VI Compliant -
CBM101S Series
Input: 90-264Vac
Outputs: 12 to 48V
Power: 100 Watt (120 Watts for 5 secs)
Tamb: -40°C to +85°C
Dims: Full Brick
UL / CE EN62368-1 Approved -
LM100-23Bxx Series
Input: 85 - 305Vac
Outputs: 5 to 24Vdc
Power: 100 Watt
Tamb: -30 to +70°C
Dims: 129 x 97 x 30mm
IEC/UL/EN62368 Approved
Very low cost -
LIMF120-23Bxx Series
Input: 85 - 277VAC / 120 - 390VDC
Outputs: 12V to 48V
Power: 120 Watt (150% for 5 secs)
Tamb: -40°C to +85°C
Dims: 124.00 x 121.00 x 34.00mm
IEC/EN/UL/BS 62368, UL61010, EN60335, EN62477, UL508 Approved
5 Years Warranty -
LGA50D Series
Input: 7.5 - 14 Vdc
Outputs: 0.6 - 5.0Vdc
Power: 120 Watts
Temp: -40 to 85˚C
Dims: 25.4x12.7x12.2mm (1x0.5x0.48")
Designed to meet IEC62368-1
LET’S MAKE THIS EASY. CALL 01929 555 700
why choose relec?
-
Faster
Our aim is to get back to you with an initial response within the hour.
-
Attention to detail
We pride ourselves on getting you the right product, at the right price and on time.
-
New ideas
We are constantly looking for latest technology and products for your applications.
-
Beyond standard
It’s not just about the product. Our service goes way beyond the norm.
-
Easy
We want to make your life as simple as it can be. Call us to find out what we can offer.
sign up for our newsletter
Enter your email address below
