iLS Series 600/1500W of Programmable DC Power

20th July 2021

iLS Series from Artesyn Embedded Power – Programmable DC Power Supplies with wireless remote sense

Advanced Energy’s Artesyn iLS Series consists of the iLS600 Series (600W) and iLS1500 Series (1500W) models. The programmable dc power supplies are available to order from Relec Electronics.

The iLS600 Series and iLS1500 Series programmable DC Power Supplies offer fast, reliable and repeatable and precise voltage source and current source measurement. The 12-bit D/A and A/D converters ensure accurate measurement in test and measurement scenarios for semiconductor testing, automatic testing equipment (ATE) and general test and measurement applications.

Advanced Energy’s patented wireless remote sensing increases accuracy by allowing dc power to be regulated at the point of load. Typically, output wires between the power supply and load can cause voltage drop or pick up noise/create ground loops but the iLS’s remote sense function ensures accurate and consistent power supply voltage over various load conditions.

iLS Series Banner By Artesyn | Programmable DC Power Supplies | Artesyn Power

The fully digital design of the iLS series uses newer technologies, architectures and components than competing alternatives. The use of readily available components ensures faster delivery to begin work on test projects quicker.

The iLS600 (front dc output), iLS600-R (rear dc output) and iLS1500 (rear dc output) power supplies offer five voltage ranges, from 0 to 30V up to 0 to 400V. All offer a wide variety of control options, including front panel manual control, Ethernet (LXI), USB, analog and LabView drivers. There is also the option for master/slave configurations, using up to four units in parallel or two units in series for 600V max.

All models are fully adjustable from 0 to max voltage or 0 to max current and cannot exceed maximum power. Safety features include adjustable over-voltage and over-current protection.

Artesyn Embedded Power | UK Trusted Distributor | Relec Electronics Ltd 2020
iLS Series 600W & 1500W, with built in LabVIEW Drivers, & Certified to CAN/CSA C22.2 # 60950-1 & 62368-1

The programmable dc power supplies can be used in ATE for production testing, avionics and military testing, EV testing, data loggers and functional testers. They are also suitable for engineering labs, product development and circuit design for R&D, national and commercial laboratories and as bench manual control and programmable power supplies in universities.

The procedure for calibration in the field is simple and straightforward. Customers can also write special scripts which can be uploaded directly. All firmware updates can be uploaded and installed in the field.

Modification and customization is available on request. These include colour choices and custom overlay, as well as specification changes, depending on volume, NRE and compliance testing considerations.

The iLS 600, iLS600-R and iLS1500 programmable DC power supplies will be available from September.

Programable DC Power Supplies from Artesyn

ILS600 Series | 1U Rack AC-DC | 600 Watt | Artesyn Embedded Power

iLS600 Series

Input: 100Vac – 240Vac
Outputs: 0-30Vdc to 0-400Vdc (5 ranges)
Power: 600W
Tamb: +10 to +40°C
Dims: 262 x 224 x 44mm
Certified to CAN/CSA C22.2 # 60950-1 & 62368-1

iLS1500 Series | 1U Rack AC-DC | 1500 Watt | Artesyn Embedded Power

iLS1500 Series

Input: 100Vac – 240Vac
Outputs: 0-30Vdc to 0-400Vdc (5 ranges)
Power: 1500W
Tamb: +10 to +40°C
Dims: 1U Compact Design
Certified to CAN/CSA C22.2 – 60950-1 & 62368-1
